GE IC695CHS012 240 milliamps at 5 Volts DC 600 milliamps at 3.3 Volts DC 24 Volts

  • 1
  • 2

Brand Name : GE

Model Number : IC695CHS012

Place of Origin : USA

Price : negotiation

Payment Terms : T/T

Supply Ability : 1

Delivery Time : 5-8 work daysRockwell Automation

Packaging Details : New in original boxRockwell Automation

Condition : new

Nominal output voltage : 120 / 240 VAC

Product Type : Output Module

warranty : 1 year

Memory Requirement : 4 bytes

Rated Voltage : 120/240 V AC

Output Voltage Range : 85/264 V AC

Weight : Supports both PCI and High Speed Serial

Contact Now

GE IC695CHS012 240 milliamps at 5 Volts DC 600 milliamps at 3.3 Volts DC 24 Volts

Product information GE IC695CHS012  :


The IC695CHS012 Universal Backplane belongs to GE Fanuc RX3i PACSystems series of baseplate modules. It comes with 12 slots and hot-swapping support. It is a dual-bus backplane that supports both PCI and high-speed serial devices.

It also supports GE Series 90-30 I/O modules and option modules. The baseplate options that are available with this module are the controller baseplate and the Ethernet expansion baseplate. It has a terminal strip on the left side to connect isolated +24 Volts DC input voltage. To maintain product reliability and performance, it must be mounted horizontally. The IC695CHS012 Universal Backplane also can be installed within a protective enclosure with an IP 54 rating or greater.

The IC695CHS012 Universal Backplane supports expansion bases to maximize flexibility. It has an internal power consumption rating of 600 milliamps at 3.3 Volts DC or 240 milliamps at 5 Volts DC. It features a backplane grounding point. The serial expansions and remote backplanes can be connected to the serial expansion connectors.

The slot numbers are printed on the backplane for easy identification. The IC695CHS012 module has an internal grounding bar to connect shield grounds or modules. This module is considered to be open equipment. When installing it in an enclosure, a minimum space of at least 4 inches required from all sides for proper heat dissipation. The leftmost slot which is known as Slot 0 of the backplane is used for installing the backplane connector of the power supplies. Slots 1 through 11 can be used to connect the PCI and serial bus compatible modules. Slot 12 is used to connect RX3i serial expansion modules.




More information:

Manufacturer GE Fanuc
Series RX3i PACSystems
Part Number IC695CHS012
Product Type Universal Backplane
Number of Slots 12
Backplane Support PCI and High-Speed Serial
Module Hot Swap Support Yes
Dimensions (HxWxD) 5.57 x 18.01 x 5.80 inches
Internal Power Used 600 mA at 3.3V DC, 240 mA at 5V DC
Enclosure Rating IP 54






 IC695CHS012 's details:


GE IC695CHS012 240 milliamps at 5 Volts DC 600 milliamps at 3.3 Volts DC 24 Volts
Another module:
IC694MDL230 120 VAC Isolated Input (8 Points)
IC694MDL231 240 VAC Isolated Input (8 Points)
IC694MDL240 120 VAC Input (16 Points)
IC694MDL241 24 VAC/VDC Input (16 Points)
IC694MDL250 120 VAC Isolated Input (16 Points)
IC694MDL260 120 VAC Input (32 Points)**
IC694MDL632 125 VDC Input (8 Points)
IC694MDL634 24 VDC Input, Neg/Pos Logic (8 Points)
IC694MDL645 24 VDC Input, Neg/Pos Logic (16 Points)
IC694MDL646 24 VDC Input, Neg/Pos Logic, 1 msec Filter (16 Points)
IC694MDL654 5/12 VDC (TTL) Input, Neg/Pos Logic, (32 Points)
IC694MDL655 24 VDC Input, Neg/Pos Logic, 1 ms, (32 Points)
IC694MDL660 24 VDC Input (32 Points)**
IC694ACC300 Input Simulator Module (8 Points)
